Tungsten Carbide First Punch for Screw Making VA80 Material

Tungsten Carbide First Punch for Screw Making VA80 Material

tungsten carbide first punch

screw making carbide punch

VA80 material carbide punch

Lugar de origen:

Chongqing, China

Nombre de la marca:

Henghui

Número de modelo:

Personalizado

Contacta con nosotros

Solicitar una cita
Tungsten Carbide First Punch for Screw Making VA80 Material Tungsten Carbide First Punch for Screw Making VA80 Material Tungsten Carbide First Punch for Screw Making VA80 Material Tungsten Carbide First Punch for Screw Making VA80 Material Tungsten Carbide First Punch for Screw Making VA80 Material Tungsten Carbide First Punch for Screw Making VA80 Material
Detalles del producto
Modo de conformación:
Forja de moldes
Material del producto:
Acero y carburo
Material de caja:
H13, SKD61
Material del carburo:
VA80
Precisión:
+/- 0.01 mm
Software de diseño:
El CAD
Tratamiento superficial:
Pulido
Contenido del Co:
20%
Tamaño de grano:
3~6
Densidad:
13.58 g/cm²
Dureza:
84.0 HRA
TRS:
280 kgf/mm²
Fuerza de impacto:
0.85 kgf/m-cm²
Desviación relativa:
0.005 mm
Concentricidad:
0.01 mm
Condiciones de pago y envío
Cantidad de orden mínima
1
PRODUCTOS RELACIONADOS
Buen precio High Precision Carbide Die for Screw Extrusion Mould en línea

High Precision Carbide Die for Screw Extrusion Mould

Consiga el mejor precio
Buen precio Custom Hex Trimming Die Carbide CVD Coating Industrial Mold en línea

Custom Hex Trimming Die Carbide CVD Coating Industrial Mold

Consiga el mejor precio
Buen precio Custom Tungsten Carbide Die Mold for Nuts M12-M20 Forging Mould en línea

Custom Tungsten Carbide Die Mold for Nuts M12-M20 Forging Mould

Consiga el mejor precio
Buen precio DC53 Thread Rolling Dies for Self Tapping Screw Making Molds en línea

DC53 Thread Rolling Dies for Self Tapping Screw Making Molds

Consiga el mejor precio
Contacta con nosotros
+8613983025528
hou@citool.com
86-023-60338218-60338218
Contacta ahora
Descripción del producto
Customized Processing Factory Shipment International Express Transportation Cold Heading Punch Die
Product Specifications
Shaping Mode Forging Mould
Product Material Steel & Carbide
Product screw die
Product Name Tungsten Carbide First Punch
Case Material H13, SKD61
Carbide Material VA80
Precision +/- 0.01mm
Design software CAD
Usage For Making Screws
Surface Polishing
Service OEM ODM
Product Description
Tungsten Carbide First Punch for Screw Making VA80 Material 0
Tungsten Carbide First Punch for Screw Making VA80 Material 1
Tungsten Carbide First Punch for Screw Making VA80 Material 2
Tungsten Carbide First Punch for Screw Making VA80 Material 3
Tungsten Carbide First Punch for Screw Making VA80 Material 4
Main material: Reasonable choice of carbide material will greatly improve the service life of die.
Material Specifications
Item Co Grain Size Density Hardness TRS Impact Strength Application
KG2 6.5% 2~3 14.90 90.5 320 0.28 Drawing die
KG3 9% 2~3 14.61 89.3 340 0.52 Extrusion die
KG5 12% 2~3 14.31 88.3 340 0.58 Extrusion die
KG6 14% 2~3 14.12 87.3 320 0.65 Extrusion die
ST6 15% 3~6 13.80 86.0 270 0.78 Stainless steel
ST7 20% 2~6 13.40 85.3 270 0.80 Stainless steel
EA65 18% 2~6 13.73 85.0 300 0.80 Carbon steel screw/cutting die
VA80 20% 3~6 13.58 84.0 280 0.85 Impact resistance
VA90 22% 6~9 13.39 82.5 240 0.90 Impact resistance
Quality Assurance
Tungsten Carbide First Punch for Screw Making VA80 Material 5
Manufacturing Facility
Tungsten Carbide First Punch for Screw Making VA80 Material 6
Tungsten Carbide First Punch for Screw Making VA80 Material 7
Tungsten Carbide First Punch for Screw Making VA80 Material 8
Tungsten Carbide First Punch for Screw Making VA80 Material 9
Company Profile
Chongqing Henghui Precision Mold Co., Ltd. is equipped with advanced manufacturing equipment including CNC lathes, machining centers, cylindrical grinding machines, EDM machines, and cutting machines. Our quality assurance is supported by Rockwell Hardness Testers, Projectors, and 3D Image Measuring Instruments.
We specialize in designing and manufacturing high-quality precision molds for cold heading and hot upsetting industries, with dimensional accuracy controlled within 0.005mm and concentricity within 0.01mm. Operating under ISO9001:2015 quality management system, we serve global clients in Southeast Asia, Europe, and the United States with our commitment to "Customer first, quality first, technology first, dedicated service".
Industry Participation
Tungsten Carbide First Punch for Screw Making VA80 Material 10
We actively participate in international fastener exhibitions including the German Fastener Exhibition and Indian Fastener Exhibition, where we showcase our products and establish valuable business connections.
Packaging & Delivery
Tungsten Carbide First Punch for Screw Making VA80 Material 11
Packaging Details: Carton Box; Export Standard Package, or as per client's requirements.
Delivery Time: 12-45 days depending on order quantity.
Frequently Asked Questions
Q1: How can I get a quotation from your company?
A1: Contact us with the following information for prompt quotation: drawings, material specifications, quantity requirements, and surface treatment preferences.
Q2: What is our lead time?
A2: Production lead time depends on order quantity and destination country.
